Food-Grade Fermentation Tanks: The Engineer's Design Guide for Breweries, Dairy & Pharma (2025)

In food and pharmaceutical fermentation processes, surface roughness (Ra) is your first defense against contamination. According to the 3-A Sanitary Standard 13-11:

- Acceptable: Ra ≤ 0.8μm (achieved only by electropolishing 316L SS)

- Unacceptable: Ra > 1.6μm (harbors Listeria and biofilms)

Lab data shows: Tanks with Ra=0.6μm require 40% less CIP chemical consumption vs. Ra=1.2μm (Journal of Dairy Science, 2024).

Critical reminder: BERCHANCE fermentation tanks are designed strictly for low-pressure processes:

- Maximum working pressure: 0.8 MPa (8 bar)

- Vacuum rating: -0.1 MPa (-1 bar) only

- Test pressure: 1.2 MPa (12 bar) hydrostatic

WARNING: Never use for high-pressure hydrogenation (>2.0 MPa) — this exceeds our manufacturing scope.

Jacket design options compared:

1. Dimple jacket: Suitable for small breweries (<5,000L), up to 0.6 MPa

2. Half-pipe coil: Ideal for dairy yogurt tanks, up to 1.0 MPa

3. Conventional jacket: For large pharma bioreactors, up to 0.8 MPa

Compliance checklist for North America:

- ASME "U" Certification required for vessels >15 psi (0.1 MPa)

- CRN Registration mandatory in all Canadian provinces

- 3-A Symbol Authorization for dairy contact surfaces

Project example: Berlin craft brewery 6,000L conical fermenter

- Material: 316L SS, 4mm shell (Ra=0.6μm)

- Design pressure: 0.3 MPa @ 25°C

- Certifications: ASME U-certified + PED compliant

- Delivery: 7 weeks from order confirmation

3 questions to ask your supplier:

1. Can you provide mill test reports (MTRs) for every batch of 316L plate?

2. How do you validate Ra values? Is it pre- or post-polish measurement?

3. What's your hydrotest documentation process?

BERCHANCE guarantee: All fermenters include free CAD drawings (.STEP/.DWG) and material traceability reports.
